What is the main difference between aramid fiber packing and graphite packing?

While both are used for high-temperature sealing, aramid fiber packing offers significantly higher tensile strength and mechanical durability, making it more resistant to extrusion and wear in dynamic applications like pump shafts. Graphite packing is often softer, offers excellent thermal conductivity and conformability, and is superb for static or slow-rotating equipment. Aramid is generally chosen for its strength and chemical resistance in aggressive, high-pressure rotating services.

Can Kaxite aramid fiber packing be used for food and pharmaceutical applications?

Standard aramid packing with PTFE or graphite lubricants is not typically certified for direct food or pharmaceutical contact. However, Kaxite Sealing can provide specialized grades with FDA-compliant lubricants or alternative constructions for such applications. It is crucial to specify your industry and media requirements when consulting with our technical team to ensure compliance.

How do I select the correct size and style of aramid packing for my pump?

Selection depends on the stuffing box dimensions, shaft/stem diameter, operating conditions (pressure, temperature, speed), and the medium being sealed. The cross-section should match the width and depth of the stuffing box. For high-speed rotary equipment, a square braid or braid-over-braid style from Kaxite is often recommended for its stability. Our technical support team can assist you in selecting the optimal product based on your equipment model and service parameters.

Why is there initial leakage after installing new aramid packing, and is it normal?

Yes, a slight initial leakage is normal and often necessary. It provides a thin film of the sealed medium (or added lubricant) to cool and lubricate the packing and shaft/stem interface. The key is the run-in procedure: after installation, the packing should be allowed to seat by gradually tightening the gland until leakage is reduced to a controlled minimum drip or film. Excessive initial tightening can cause overheating, rapid wear, and shaft damage.

What chemicals should aramid fiber packing NOT be used with?

While aramid has excellent chemical resistance, it has limitations. It is not recommended for use with strong mineral acids (e.g., concentrated sulfuric, nitric acid) at high temperatures, or with strong oxidizing agents. The organic polymer structure of aramid can degrade under these extreme conditions. For such services, fully fluorinated materials like PTFE or specialized graphite packings may be more suitable. Always consult the Kaxite Sealing chemical resistance chart for your specific media.

How does Kaxite Sealing ensure the quality of its aramid fiber packing?

Kaxite Sealing implements a rigorous quality management system. We start with sourcing high-grade raw aramid fibers and lubricants. Our manufacturing process involves controlled braiding and impregnation techniques. Every production batch undergoes a series of tests, including dimensional checks, density verification, and performance sampling for key parameters like tensile strength and thermal stability. This end-to-end control ensures that every spool of Kaxite packing delivers consistent, reliable performance.

Can this packing be used in abrasive slurry services?

Aramid fiber packing has good abrasion resistance compared to many soft packings, but in highly abrasive slurry services, pure aramid may experience accelerated wear. For such applications, Kaxite Sealing offers reinforced or composite packings that combine aramid fibers with other materials like inconel wire or additional abrasion-resistant inhibitors to extend service life. A technical assessment of the specific slurry composition and particle size is recommended.
